Researchers 3-D Print Cartilage to Create a Trachea

Investigators at The Feinstein Institute for Medical Research have made a medical breakthrough using 3-D printing on a MakerBot Replicator 2X Experimental 3-D printer to create cartilage designed for tracheal repair or replacement. The results were reported during the 51^st annual meeting of the Society of Thoracic Surgeons in San Diego, Calif., in a presentation by Todd Goldstein, an investigator at the Feinstein Institute in Manhasset, N.Y., which is part of the North Shore-LIJ Health System. This is a first for medical research, according to the Feinstein Institute, where regular MakerBot polylactic acid (PLA) filament was used to 3-D print a custom tracheal scaffolding, which was combined with living cells to create a tracheal segment.

Goldstein, a Ph.D. candidate at the Hofstra North Shore-LIJ School of Medicine, has been working with a team of surgeons for the past year on determining if 3-D printing and tissue engineering could be used for tracheal repair and replacement. Tracheal damage can be caused by tumor, endotracheal intubation, blunt trauma, and other injuries. Narrowing and weakness of the trachea can occur and are often difficult to repair. There have been two traditional means of reconstructing a damaged trachea, but both techniques have limitations.

Lee Smith, M.D., chief of pediatric otolaryngology at Cohen Children’s Medical Center in Hyde Park, N.Y., and David Zeltsman, M.D., chief of thoracic surgery at Long Island Jewish Medical Center (also in Hyde Park), both part of the North Shore-LIJ Health System, came to Goldstein and Daniel A. Grande, Ph.D., director of the Orthopedic Research Laboratory at the Feinstein Institute, and asked if 3-D printing might offer a solution. Smith and Zeltsman originally surmised that incorporating 3-D printing and tissue engineering to grow new cartilage for airway construction might be possible in ten to 20 years. Goldstein and Grande did it in a month.

The Feinstein Institute’s research combined two emerging fields: 3-D printing and tissue engineering. Tissue engineering is like other kinds of engineering, except instead of using steel or computer code to make things, living cells from skin, muscle or cartilage are the raw material. Researchers at the Feinstein Institute know how to make cartilage from a mixture of cells called chondrocytes, nutrients to feed them, and collagen, which holds it all together. Shaping that cartilage into a nose or a windpipe is another matter. That’s where 3-D printing comes in. A 3-D printer can construct scaffolding, which can be covered in a mixture of chondrocytes and collagen, which then grows into cartilage.

“Making a windpipe or trachea is uncharted territory,” noted Goldstein. “It has to be rigid enough to withstand coughs, sneezes and other shifts in pressure, yet flexible enough to allow the neck to move freely. With 3-D printing, we were able to construct 3D-printed scaffolding that the surgeons could immediately examine and then we could work together in real time to modify the designs. MakerBot was extremely helpful and consulted on optimizing our design files so they would print better and provided advice on how to modify the MakerBot Replicator 2X Experimental 3-D printer to print with PLA and the biomaterial. We actually found designs to modify the printer on MakerBot’s Thingiverse website to print PLA with one extruder and the biomaterial with the other extruder. We 3-D printed the needed parts with our other MakerBot Replicator Desktop 3-D printer, and used them to modify the MakerBot Replicator 2X Experimental 3-D printer so that we could better iterate and test our ideas.”

“The ability to prototype, examine, touch, feel and then redesign within minutes, within hours, allows for the creation of this type of technology,” said Smith. “If we had to send out these designs to a commercial printer far away and get the designs back several weeks later, we’d never be where we are today.”

The Feinstein Institute previously had looked at other 3-D printers that can extrude living cells, but the options are few and expensive. One special bio printer cost $180,000, an amount that the institute would not allocate. They wanted to test their concept and see if it would be viable, so they decided to use the more affordable and accessible MakerBot Replicator 2X Experimental 3-D printer that retails for $2,499 and is a size that fits on a desktop.

Originally, Goldstein thought that he would need special PLA to maintain sterility and have the ability to dissolve in the body. However, in light of time, they decided to try regular MakerBot PLA filament. “The advantage of PLA is that it’s used in all kinds of surgical implant devices,” said Smith. Through testing, Goldstein found that the heat from the extruder head sterilized the PLA as it printed, so he was able to use ordinary MakerBot PLA filament.

The bio-ink, which stays at room temperature, is extruded during the 3-D printing process and fills in gaps in the PLA scaffolding, then cures into a gel on the heated build plate of the MakerBot Replicator 2X. A two-inch-long section of windpipe—shaped like a hollowed-out Tootsie Roll—takes less than two hours to print. Once the bio-ink adheres to the scaffolding, it goes into a bioreactor, an appliance like a rotisserie oven that keeps the cells warm and growing evenly. A new bioreactor costs between $50,000 and $150,000, so Goldstein customized an incubator for his needs, making gears and other parts on their MakerBot Replicator Desktop 3-D printer to produce a brand new bioreactor.

“The research being done at the Feinstein Institute is exciting and promising,” noted Jenny Lawton, CEO of MakerBot. “We are continually amazed by what is being created with 3-D printers. To know that a MakerBot Replicator 3D Printer played a role in a potential medical breakthrough is inspiring.”

The results of the study, as presented by Goldstein and Zeltsman at The Society of Thoracic Surgeons, illustrate how the 3-D printed windpipe or trachea segments held up for four weeks in an incubator. According to Goldstein’s abstract, “The cells survived the 3-D printing process, were able to continue dividing, and produced the extracellular matrix expected of tracheal chondrocytes.” In other words, they were growing just like windpipe cartilage.

The Feinstein Institute describes this work as a “proof of concept.” The team still has work to do before establishing a new protocol for repairing damaged windpipes. Medical research can take years to move from bench to bedside, as can U.S. Food and Drug Administration (FDA) approval. However, if there is no approved treatment for an ailment, the FDA has a compassionate therapy exception that allows the patient to agree to try an experimental approach.

According to Smith, at least one patient comes through the North Shore-LIJ Health System each year who can’t be helped by the two traditional methods, and he expects in the next five years to harvest a patient’s cells, grow them on a scaffolding, and repair a windpipe. This customized approach may prove to be especially useful for treating children, Smith said. “There’s really a limitless number of sizes and permutations you might need to reconstruct an airway in a child.”

When speaking about his work with 3-D printing and this research, Goldstein noted: “It’s completely changed the trajectory of my academic career.”

Goldstein originally came to the Feinstein Institute as a molecular biologist, working with cells, chemicals and drugs. Combining this knowledge with 3-D printing and getting into tissue engineering is something he didn’t expect that at all when he joined the Feinstein Institute.

Now he is the Feinstein Institute’s 3-D printing specialist, printing models of organs for pre-operative planning and tools to improve the lab. He is the presenting author on a paper being presented to thousands of surgeons, and applying for major grants to continue his research. “Knowing that I can make a part that will save someone’s child—that’s life-changing,” said Goldstein.

“This project will probably define my scientific career,” said Smith. “As we produce something that can replace a segment of trachea, we’ll constantly be modifying and optimizing, the correct bio materials, the correct way to bond the cells to the scaffold. 3-D printing and tissue engineering has the potential to replace lots of different parts of the human body. The potential for creating replacement parts is almost limitless.”

MakerBot also has supplied the Feinstein Institute with early samples of its just-announced MakerBot PLA composite filaments in limestone (calcium carbonate) and iron, which will be available commercially later this year, so the Feinstein Institute can start investigating how to engineer other kinds of tissue, such as bone or 3-D print custom-made shields for cancer and radiation treatment.

“Do you remember the “Six Million Dollar Man” [TV program]?” asks Grande. “The bionic man is not the future, it’s the present. We have that ability to do that now. It’s really exciting.”

MakerBot is a subsidiary of Stratasys Ltd.

The Feinstein Institute for Medical Research is home to international scientific leaders in many areas including Parkinson’s disease, Alzheimer’s disease, psychiatric disorders, rheumatoid arthritis, lupus, sepsis, human genetics, pulmonary hypertension, leukemia, neuroimmunology, and medicinal chemistry.
