3D Printed Microfibers Could Speed Development of Artificially Grown Body Parts

Much as a frame provides structural support for a house and the chassis provides strength and shape for a car, a team of Penn State engineers believe they have a way to create the structural framework for growing living tissue using an off-the-shelf 3D printer.

“We are trying to make stem-cell-loaded hydrogels reinforced with fibers like the rebar in cement,” said Justin L. Brown, associate professor of biomedical engineering. “If we can lend some structure to the gel, we can grow living cells in defined patterns and eventually the fibers will dissolve and go away.”

The researchers report in a recent issue of the Journal of Advanced Healthcare Materials that their aim is to create a novel, low-cost and efficient method to fabricate high-resolution and repeatable 3D polymer fiber patterns on nonconductive materials for tissue engineering with available hobbyist-grade 3D printers. The method they use is a combination of 3D printing and electrospinning, a method that uses electric charge to spin nanometer threads from either a polymer melt or solution.

Currently nearly all complex transplant tissues, from hearts and kidneys to tendons, come from living or dead donors. The researchers are looking for a way to grow replacement tissues reliably using inexpensive methods. The combination of 3D printing and electrospinning to produce a scaffold for tissue engineering might also enable production of combined muscles and tendons, or tendons and cartilage, for example.

“The overarching idea is that if we could multiplex electrospinning with a collagen gel and bioprinting, we could build large and complex tissue interfaces, such as bone to cartilage,” said Pouria Fattahi, doctoral student in bioengineering. “Others have created these combination tissues using a microextrusion bioprinter.”

These current strategies create the different tissues separately and then combine them using some type of adhesive or connector. However, in the body, tissues such as cartilage and bone, and tendons and muscles, grow seamlessly together.

The researchers’ apparatus uses the electrospinner to replace the extruder nozzle on the 3D printer. The printer can deposit a precise pattern of fibers in three dimensions to form a scaffold in a hydrogel on which cells can grow. Once the tissue has grown sufficiently, the scaffolding can be dissolved, leaving only a structured tissue appropriate for use.

If two different tissues—muscle and tendon—are needed, the 3D printer can alter the pattern of threads in such a way that the transition could be seamless with the appropriate cells, resulting in a naturally formed, two-part tissue replacement.

Currently, the researchers are working on tissues that are a little less than 1 inch cubes, but even that might have some utility.

“The anterior cruciate ligament, or ACL, is only about 2 to 3 centimeters (.8 to 1 inch) long and 1 centimeter (.8 inches) wide,” said Fattahi.

Using near-field electrospinning, the researchers first produced exceptionally thin threads in the micron and nanometer range. They next showed that they could grow cells on these fibers and finally, deposited patterned fibers into a collagen gel loaded with cells.
